FIBERTECH

Instrument Details


Make: Foss, Denmark
Model: FibertechTM1023
Specification:Filtration Module complete, comprising: Filtration Module, Incubation Flasks (4 sets of 6), Standard Crucibles (P2, 2 sets of 6), Basket for Incubation Flasks, 2 Stands for Crucibles, 2 Spray bottles, 2 Water aspiration pumps, Filter aid, Tubing, WB 1024 Water bath, complete, comprising: a tray for 12 Incubation Flasks and a hinged inclined lid.Filtration module as above but without WB 1024 Water bath.
The Fibertec™ 1023 determines total dietary fibre as well as the insoluble and soluble fibres separately.It is also useful in sample preparation for detailed studies of fibre fractions, e.g. by chromatographic or colorimetric techniques.

Working Principle

The system includes a shaking water bath and a filtration module for quantitative determination of dietary fibre in a variety of sample types. The filtration module filters and collects six sample solutions and includes a system for rapid dehydration. The filtration step is speeded up through a built-in “Pressure Mode”, to break up clogged filter residues during filtration. Filtration time varies from 2-4 minutes for 100 ml of digested solution. The WB 1024 Water bath incubates 12 samples in each batch. The temperature range is from ambient up to 80°C and it is possible to preset three temperatures.
Batch handling processes up to 6 samples at a time saving time. Laboratories around the globe have invested in Fibertec™ instruments that go on working year after year, making Fib-ertec™ a solution that will keep your lab up to speed, well into the future.

Applications

1. Total Dietary Fibre (TDF) according to AOAC 991.43 and AACC 32-07
2. Soluble (SDF) and Insoluble (IDF) Dietary Fibre according to AOAC 991.42/43 and AACC 32-07
3. Total Dietary Fibre (TDF) according to AOAC 985.29 and AACC 32-05
4. Soluble (SDF) and Insoluble (IDF) Dietary Fibre according to AOAC 985.29 and AACC 32-05
5. Integrated Total Dietary Fibre (ITDF) Codex Definition method according to AOAC 2009.01

User Instructions

1. Sample must be defatted
2. Water rotation should be maintained.
Contact Us: Dr. B Dayakar Rao

Phone: 040-24599331
E-mail: dayakar@millets.res.in



Costing
Parameter Industry University National Labs/R&D's
Estimation of total diary fibre Rs 3000 Rs 750 Rs 1500 Per sample


Kindly include this note in your requesting letter exactly as it is :

"Content of this report is meant for our information only and we will not use the content of this report for advertisement, evidence, litigation or quote as certificate to third party"
